Description
TECHNICAL AND FUNCTIONAL CHARACTERISTICS
• Low NOx and CO emissions gas burner compliant with European standard EN676 “Classe Ill”.
• Two-stage operation (high/low flame).
• Suitable for operation with any type of combustion chamber, according to standard EN 303.
• High ventilation efficiency, low electrical input, low noise.
• Air-gas mixing at blast-pipe.
• Exhaust gas recycling blast-pipe able to achieve very low pollutant emissions. particularly with
regard to nitrous oxides (NOx).
CONSTRUCTION CHARACTERISTICS
The burner consists of:
• Light aluminium alloy fan part.
• High performance centrifugal fan.
• Air intake with butterfly gate for the regulation of the air combusting flow rate. with sound insulation and designed for optimal air damper opening linearity.
• Combustion air input
• Sliding boiler coupling flange to adapt the head protrusion to the various types of boilers.
• Stainless adjustable combustion head, equiped by stell flame disk.
• Flame viewer.
• Mono-phase electric motor to run fan.
• Air pressure switch to ensure the presence of combustion air.
• Air flow regulation for first and second stage by means of electric servomotor.
